Taco 1610D Stainless Steel Pump 1/3HP 1PH

Move potable water through commercial loops with Taco 1610D, a 1/3 HP stainless-steel in-line centrifugal pump rated for up to 65 GPM and 32 feet of head. Its 115 V single-phase motor, 1-1/2-inch two-bolt flange, and lead-free stainless-steel casing suit open-loop applications where material selection and electrical simplicity both matter. Verify the system curve before installation.

The 1725 RPM ODP motor uses a close-coupled drive with maintenance-free sealed ball bearings, internal thermal overload, and a one-piece cast-bronze impeller. The pump is rated for 175 psi, 40°F to 250°F fluid, and a 12-inch flange-to-flange length. Check the 5.8 amp full-load current, 48-pound dry weight, pipe alignment, and NSF/ANSI 372, UL, and CSA requirements before startup.

Key Features & Benefits

- 1/3 HP Motor: Supports commercial hot-water recirculation and compatible open-loop applications.
- 115 V Single-Phase: Fits compatible US service panels without requiring three-phase power.
- 65 GPM Maximum Flow: Handles substantial potable-water circulation within the stated performance range.
- 32 Feet Maximum Head: Provides a clear reference for system-resistance comparison.
- Stainless-Steel Body: Provides a lead-free casing material for specified open-loop service.
- 1-1/2-Inch Two-Bolt Flange: Helps contractors verify replacement piping compatibility.
- 175 psi Maximum Pressure: Establishes the listed pressure boundary for compatible installations.
- Maintenance-Free Bearings: Reduce routine bearing service during normal operation.

Why Choose Taco 1610D

The Taco 1610D combines stainless-steel construction, 115 V power, and clearly stated hydraulic and dimensional data for commercial potable-water circulation and open-loop service.

- Build: Stainless steel, cast bronze impeller, cupro-nickel shaft sleeve, ceramic seal face, and sealed bearings define the pump assembly.
- Value: The listed flow, head, pressure, dimensions, and full-load current help contractors plan a more accurate replacement.
- Audience: Suited to plumbing contractors, hotel maintenance teams, apartment engineers, and commercial hot-water specialists.

Applications & Use Cases

Use Taco 1610D for potable-water circulation, commercial hot-water recirculation, hotels, apartments, and compatible open-loop systems. The pump has a 12-inch flange-to-flange length and weighs 48 pounds dry, with a 1-1/2-inch two-bolt flange. Confirm pipe support, valve clearance, pump orientation, and service access before installation.

Warranty & Support

- Warranty Terms Require Confirmation: Verify duration, coverage, registration, exclusions, and authorized service requirements with Taco or the seller.
- Match model 1610D, 1/3 HP motor, 115 V supply, 5.8 amp rating, and flange dimensions before ordering.

Flush the piping, purge air, verify the 115 V supply, and inspect the ceramic seal area before startup. Confirm operating pressure, fluid temperature, flow, and motor protection during commissioning. Purchase the Taco 1610D stainless-steel in-line centrifugal pump through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
