Taco 1600D Stainless Steel Pump 1/4HP

Potable-water systems use Taco 1600D for domestic hot-water recirculation and open-loop circulation. Its 1/4 HP, 115 V single-phase motor operates at 1725 RPM, delivering up to 45 GPM against 18 feet of head through a stainless steel body. Confirm NSF/ANSI 372 compliance, the 175 PSI pressure rating, flange alignment, and motor protection before startup.

The Taco 1600D uses a close-coupled NEMA 56 frame motor with 4.4 amp full-load current and a 1.5-inch two-bolt flange. Its cast bronze impeller, alloy steel shaft with cupro-nickel sleeve, ceramic-face EPT seal, and 40°F to 250°F fluid range support potable-water circulation. The pump also includes internal thermal overload, maintenance-free sealed ball bearings, UL and CSA approvals, a 12-inch flange-to-flange length, and 46-pound dry weight.

Key Features of Taco 1600D

- 1/4 HP motor supports domestic hot-water recirculation and potable-water systems.
- 115 V single-phase operation suits compatible commercial plumbing circuits.
- 4.4 amp full-load rating assists branch-circuit and protection planning.
- 1725 RPM operation supports close-coupled domestic-water circulation performance.
- 45 GPM maximum flow handles compatible open-loop water systems.
- 18-foot maximum head supports domestic hot-water distribution requirements.
- 1.5-inch two-bolt flange supports standard replacement installation planning.
- Stainless steel body, bronze impeller, alloy shaft, cupro-nickel sleeve, and EPT seal support potable service.
- 175 PSI pressure, 250°F temperature, 12-inch length, and 46-pound weight guide installation planning.

Why Choose Taco 1600D

This Taco stainless steel circulator combines potable-water construction with defined hydraulic performance and internal thermal protection.

- Build: Stainless steel, bronze, alloy steel, cupro-nickel, and ceramic-seal components support potable-water service.
- Value: Maintenance-free bearings and close-coupled construction can reduce routine service work and replacement complexity.
- Audience: Plumbing contractors, domestic-water installers, hotel technicians, commercial HVAC teams, and facility maintenance managers can specify this model.

Applications & Use Cases

Use the Taco 1600D for domestic hot-water recirculation, potable-water circulation, open-loop systems, and compatible commercial plumbing. Its 12-inch flange-to-flange length, 46-pound dry weight, and 1.5-inch connection support planning around pipe spacing, valve access, motor clearance, wiring, and lifting requirements.

Warranty & Support

- Warranty: A model-specific factory warranty term for the Taco 1600D was not verified and requires confirmation through Taco or the authorized seller.
- Verify 115 V wiring, purge trapped air, inspect the ceramic-face seal, confirm thermal protection, and check flow direction during commissioning.

Clean strainers, monitor the stainless steel body for leakage, verify potable-water conditions, and inspect the flange during scheduled service. Purchase the Taco 1600D stainless steel potable-water circulator from Mulmotor.com for authentic equipment, applicable factory warranty protection, and pump support.
