NEW Briggs & Stratton 305447-0523-F1 Horizontal Engine SALE !!

NEW Briggs & Stratton 305447-0523-F1 Horizontal Engine SALE !! is 479cc and puts out 16.0 HP (maximum horsepower). This Vanguard V-twin has a 1″ x 3″ crankshaft with a 1/4″ keyway. Briggs & Stratton Vanguard engines are designed with advanced technologies and integrated components to be both compact and powerful enough to take on the most demanding commercial jobs. Common applications include power packs and generators, commercial mowers and golf and turf equipment. Buyer protection package provides three-year limited consumer engine warranty. 50-State CARB Compliant. All engines purchased from us ship for free and are foam packed for added protection during transit.

Key Specifications

BRAND Briggs & Stratton

MODEL NUMBER 305447-0523-F1

REPLACES MODELS 294447-1224-A1, 294447-1213-E1, 294447-1213-A1, 294447-1204-E1, 294447-1204-A1, 294447-1187-E1, 294447-1187-A1, 294447-1183-E1, 294447-1183-A1, 294447-1182-A1, 294447-1173-A1, 294447-1170-A1, 294447-1165-E9, 294447-1165-E1, 294447-1165-A1, 294447-1151-A1, 294447-1142-A1, 294447-1132-A1, 294447-1131-A1, 294447-1130-A1, 294447-1122-E9, 294447-1122-E1, 294447-1122-A1, 294447-1118-A1, 294447-1117-A1, 294447-1116-A1, 294447-1076-A1, 294447-1056-E1, 294447-1056-A1, 294447-1054-A1, 294447-1029-A1, 294447-1014-A1, 294447-1013-A1, 294447-0432-01, 294447-0430-01, 294447-0422-01, 294447-0418-01, 294447-0417-01, 294447-0376-01, 294447-0354-01, 294447-0314-01, 294447-0313-01, 294447-0107-01, 294446-1211-E1, 294446-1211-A1, 294442-1085-E1, 294442-1085-A1, 294442-1060-A1, 294442-0480-01, 294442-0479-01, 290447-1160-A1, 290447-1153-A1, 290447-1152-A1, 290447-1137-A1, 290447-1094-A1, 290447-1076-A1, 290447-1074-A1, 290447-1073-A1, 290447-0502-01, 290447-0460-01, 290447-0453-01, 290447-0452-01, 290447-0444-01, 290447-0442-01, 290447-0441-01, 290447-0440-99, 290447-0439-01, 290447-0437-01, 290447-0428-01, 290447-0423-01, 290447-0419-01, 290447-0418-01, 290447-0394-01, 290447-0376-01, 290447-0373-01, 290447-0358-01, 290447-0355-01, 290447-0354-01, 290447-0349-99, 290447-0328-99, 290447-0327-99, 290447-0316-99, 290447-0076-01, 290447-0073-99, 290447-0058-02, 290447-0058-01, 290447-0049-02, 290447-0049-01, 290447-0035-99, 290447-0035-01, 290447-0033-01, 290447-0032-99, 290447-0032-02, 290447-0032-01, 290446-1163-A1, 290446-1114-A1, 290446-0421-01, 290446-0407-01, 290446-0124-01, 290442-1147-A1, 303447-1323-E1, 303447-1323-E9

WARRANTY 3 Year Consumer & Commercial

SHIPPING WEIGHT 98

DISPLACEMENT 479cc

STARTER TYPE Electric with Recoil Backup

CRANKSHAFT ORIENTATION Horizontal

CRANKSHAFT TYPE Straight

FUEL SYSTEM Gasoline

GEAR REDUCTION No

CRANKSHAFT DIMENSIONS 1″ x 2-29/32″

CRANKSHAFT LENGTH 2-29/32″

CRANKSHAFT END TAPPED SIZE 3/8 – 24

CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) Counterclockwise

BEARING TYPE Ball

CYLINDERS 2

CYLINDER BORE TYPE Cast Iron Sleeve

AIR CLEANER TYPE Dual Element

FUEL TANK Yes

FUEL PUMP Yes

OIL COOLER No

OIL CAPACITY 48

LOW OIL ALERT Yes

LOW OIL SHUTDOWN No

IGNITION SYSTEM Electronic

CARBURETOR TYPE Float

CHOKE CONTROL Manual and Remote

MAX RPM 3600

CHARGING SYSTEM 16

BOLT CIRCLE 5, 6-1/2, 7-3/4

FLYWHEEL Heavy

NOTES Engine Notes:

PTO HEIGHT 5 – 1/4
