Jabiru 3300cc Aircraft Engine

The Jabiru 3300cc Aircraft Engine is a 6-cylinder 4-stroke horizontally opposed air cooled engine.

Overall dimensions are extremely small. It’s 596mm (23.46″) width allows tractor applications with very small frontal areas. The Jabiru engine is designed for either tractor or pusher installation.

At 81kg installed weight the Jabiru 3300 Aircraft Engine is an ideal replacement for the 100-120 hp equivalent which power many of the existing “experimental” aircraft. It is an engine designed by aircraft designers for aircraft applications!

Engine Features

- 4 Stroke
- 3300cc (200 cubic inches)
- 6 Cylinder Horizontally Opposed
- 1 Central Camshaft
- Fully Machined Aluminium Alloy Crankcase
- Over Head Valves (OHV) – Push Rod Operated
- Ram Air Cooled
- Wet Sump Lubrication – 4 litre capacity
- Direct Propeller Drive
- Dual Transistorised Magneto Ignition
- Integrated AC Generator
- Electric Starter
- Mechanical Fuel Pump
- Naturally Aspirated – 1 Pressure Compensating Carburetor
