Give Honda BF40D4LHA a place on an aluminum fishing boat or work skiff when 40 HP, a 20-inch shaft, and direct tiller control are required. Its 808 cc inline three-cylinder SOHC 4-stroke engine uses six valves and produces 40 HP at 5,500 RPM. Honda BF40D4LHA is a Signature Silver outboard with Programmed Fuel Injection, BLAST, electric starting, a multi-function tiller handle, and gas-assist or manual tilt. The long shaft is intended for compatible 20-inch transoms.

At 225 lbs dry, this tiller configuration should be included in transom, trailer, and overall boat-balance calculations. The 5,000–6,000 RPM full-throttle range provides a reference for propeller selection, while the 2.08:1 gear ratio supports standard forward, neutral, and reverse operation. Its 22-amp alternator supplies 17 charging amps for supported electronics, lighting, pumps, and accessories. The listed engine oil capacity is 2.1 L with filter, while gearcase lubricant and service intervals should follow the applicable Honda owner’s manual.

Key Features of Honda BF40D4LHA

- Fit the 20-inch long shaft to compatible aluminum fishing boats and work skiffs.
- 808 cc Engine — uses an inline three-cylinder SOHC 4-stroke configuration with six valves.
- 40 HP at 5,500 RPM provides a defined power option for approved hulls.
- 225 lbs dry weight requires suitable transom capacity and careful boat-balance planning.
- Programmed Fuel Injection with BLAST manages fuel delivery and listed low-speed acceleration response.
- Multi-Function Tiller Handle keeps steering and throttle control directly at the motor.
- Gas-Assist or Manual Tilt helps position the engine during shallow-water use and storage.
- 22 amps total with 17 charging amps support compatible onboard equipment.

Why Choose the Honda BF40D4LHA

This model combines 40 HP with tiller operation for boaters who want direct control of a larger aluminum hull. Fuel injection simplifies the supplied engine system, while gas-assist tilt helps with positioning when launching, storing, or approaching shallow water.

- 40 HP supports approved work boats
- Tiller control keeps operation direct
- 17 charging amps support onboard accessories

Applications & Use Cases

Honda BF40D4LHA is intended for aluminum fishing boats, work skiffs, and similar 20-inch-transom hulls. It can support fishing, shoreline utility work, harbor travel, and recreational boating when the vessel accepts the engine’s weight, horsepower, and tiller-control arrangement.

- Aluminum fishing boats with long transoms
- Work skiffs using tiller controls
- Utility boats requiring 40 HP

Warranty, Support & Maintenance

The supplied product information lists a 5-year non-declining standard warranty. Follow the Honda owner’s manual for the 2.1 L oil capacity with filter, gearcase lubricant, filters, spark plugs, cooling-system checks, tiller controls, and tilt service. Confirm warranty registration, maintenance intervals, and dealer support before purchase.
