Place Honda BF5DHLHC on a sailboat kicker, small fishing tender, or utility skiff when a 20-inch shaft and low carrying weight are more important than high horsepower. Its 127 cc single-cylinder OHV 4-stroke engine produces 5 HP at 5,500 RPM and uses carbureted fuel delivery. Honda BF5DHLHC is a portable outboard with manual recoil starting, a tiller handle, five-position manual tilt, an internal 1.5 L tank, and an external tank connector.

At 61.7 lbs dry, this long-shaft motor remains manageable for owners who move the engine between storage and the boat. The 4,500–5,500 RPM full-throttle range provides a reference for setup, while the 2.08:1 gear ratio supports forward, neutral, and reverse operation. Alternator output is listed as optional, so electrical capability should be confirmed before connecting equipment. The low-oil alert provides an additional monitoring feature for routine operation.

Key Features of Honda BF5DHLHC

- Fit the 20-inch long shaft to compatible sailboats, tenders, and utility skiffs.
- 127 cc Engine — uses a single-cylinder OHV 4-stroke configuration.
- 5 HP at 5,500 RPM suits properly rated small-boat applications.
- 61.7 lbs dry weight supports easier carrying, mounting, and seasonal storage.
- Internal 1.5 L Tank — keeps fuel storage within the portable motor package.
- External Tank Connector allows connection to a compatible remote fuel supply.
- Five-position manual tilt changes lower-unit clearance during selected shallow-water and storage situations.
- Low Oil Alert monitors the listed engine-protection function during operation.

Why Choose the Honda BF5DHLHC

The 20-inch shaft makes this model suitable for small boats with higher transoms, while the 61.7-lb weight keeps handling manageable. Its internal tank, external connector, and manual controls give owners flexibility for short trips or longer auxiliary use.

- 20-inch shaft fits compatible high transoms
- 61.7-lb weight supports portable handling
- Internal tank simplifies short trips

Applications & Use Cases

Honda BF5DHLHC is intended for sailboat kicker applications, small fishing tenders, utility skiffs, and compatible 20-inch-transom boats. It can support harbor movement, shoreline access, tender travel, and auxiliary propulsion when the vessel is rated for 5 HP.

- Sailboat kicker installations
- Small fishing tenders
- Utility skiffs with long transoms

Warranty, Support & Maintenance

The supplied product information lists a 5-year non-declining standard warranty. Follow the applicable Honda owner’s manual for carburetor service, engine oil, low-oil alert checks, spark plug inspection, fuel-tank care, external fuel connections, manual tilt, and storage preparation. Confirm alternator availability, service intervals, and dealer support before purchase.
