Equip Honda BF30DK3LRTC when a small fiberglass runabout, console fishing boat, or pontoon needs remote steering, Power Trim and Tilt, and a 20-inch shaft. Its 552 cc inline three-cylinder SOHC 4-stroke engine uses six valves and produces 30 HP. Honda BF30DK3LRTC is an electric-start outboard with remote steering, three carburetors with accelerator pumps, a 10-amp alternator, and a 20-inch long shaft. The configuration is intended for compatible long-transom boats.

At 172 lbs dry, the motor should be included in the boat’s transom, battery, rigging, trailer, and balance calculations. The supplied 5,500–6,300 RPM operating range provides a reference for propeller selection, while the 2.09:1 gear ratio supports standard forward, neutral, and reverse operation. Power Trim and Tilt lets the operator change engine angle from the helm during acceleration, cruising, docking, and trailering. Confirm the hull rating and existing steering components before installation.

Key Features of Honda BF30DK3LRTC

- Mount the 20-inch long shaft on compatible fiberglass runabouts and console boats.
- Power Trim and Tilt — changes engine angle from remote helm controls during normal operation.
- 30 HP output comes from a 552 cc inline three-cylinder SOHC 4-stroke engine.
- 172 lbs dry weight requires careful transom capacity, battery, and rigging-load planning.
- Remote Steering keeps throttle and directional control at the boat’s helm.
- Three Carburetors with Accelerator Pumps manage fuel delivery within the listed system.
- Electric Start simplifies starting for regular recreational and fishing use.
- 10-amp alternator supports compatible navigation displays, lighting, pumps, and onboard accessories.

Why Choose the Honda BF30DK3LRTC

This configuration combines remote helm operation with full Power Trim and Tilt, making it more equipped than a basic tiller model. The 20-inch shaft suits long transoms, while 30 HP provides a defined power target for properly rated small boats.

- Remote steering suits console layouts
- Power trim supports helm-based adjustment
- 30 HP fits approved recreational boats

Applications & Use Cases

Honda BF30DK3LRTC is suited to small fiberglass runabouts, console fishing boats, and pontoons using a compatible 20-inch transom. It can support fishing, family outings, harbor travel, and short cruising trips when the hull accepts the engine’s weight, horsepower, and remote-control layout.

- Small fiberglass runabouts
- Console fishing boats with long transoms
- Small pontoons using remote steering

Warranty, Support & Maintenance

Routine service should follow the applicable Honda owner’s manual and include engine oil, gearcase lubricant, filters, spark plugs, carburetor service, cooling-system inspection, battery care, remote controls, and Power Trim and Tilt checks. Confirm the listed dry weight, 2.09:1 gear ratio, service intervals, warranty registration, and dealer coverage before purchase.
