Install the Honda BF140AK1XDA 140HP Outboard on a digital-ready offshore center console that requires a 25-inch shaft and standard rotation. Its 2,354 cc inline four-cylinder DOHC engine uses 16 valves and VTEC technology, producing 140 HP at 5,500 RPM for properly rated recreational hulls. Honda BF140AK1XDA is a Grand Prix White 4-stroke outboard with Programmed Fuel Injection, electric starting, Intelligent Shift and Throttle, and Power Trim & Tilt. The standard-rotation layout is intended for compatible iST installations.

At 485 lbs dry, this model should be included in transom strength, repower, and boat-balance calculations. The 25-inch X-long shaft suits boats with taller transoms, while the 5,000–6,000 RPM full-throttle range provides a reference for propeller selection. The 40-amp alternator supplies 30 charging amps for supported navigation systems, pumps, lighting, and other equipment. Engine oil capacity is listed at 6.7 L with filter; gearcase service should follow the applicable Honda manual.

Honda BF140AK1XDA White iST 25-Inch Outboard for Digital Helm Systems

- Fit the 25-inch X-long shaft to boats designed for compatible tall-transom mounting.
- Grand Prix White Finish — provides the listed exterior color for this standard-rotation iST model.
- 140 HP at 5,500 RPM comes from a 2,354 cc DOHC four-cylinder engine.
- 485 lbs dry weight belongs in transom, repower, and boat-balance calculations.
- Intelligent Shift and Throttle provides drive-by-wire control for supported digital helm systems.
- Programmed Fuel Injection manages fuel delivery within the specified 4-stroke engine package.
- Power Trim & Tilt adjusts the running position from compatible iST controls.
- 40 amps total with 30 charging amps support onboard electrical accessories.

Why Choose the Honda BF140AK1XDA

This model combines a white finish, standard rotation, iST controls, and a 25-inch shaft for digital-ready offshore boats. The 140 HP rating gives a properly approved center console a defined propulsion option, while electronically managed shifting and throttle keep primary operation at the helm.

- Standard rotation suits compatible digital installations
- 25-inch shaft matches compatible tall transoms
- Grand Prix White finish complements selected boats

Applications & Use Cases

Honda BF140AK1XDA is suited to modern offshore center consoles using a 25-inch transom and compatible iST rigging. It can be used for offshore fishing, coastal cruising, harbor travel, and family boating when the vessel supports the engine’s weight, horsepower, shaft length, and digital-control requirements.

- Offshore center consoles with tall transoms
- Digital-ready boats using standard rotation
- Recreational fishing with iST controls

Warranty, Support & Maintenance

The supplied product information lists a 5-year non-declining standard warranty. Follow the applicable Honda owner’s manual for the 6.7 L oil capacity with filter, gearcase lubricant service, filters, spark plugs, cooling-system inspection, iST controls, and Power Trim & Tilt. Confirm digital compatibility, warranty registration, and authorized dealer support before purchase.
