Bell & Gossett Series e-1532 2.5BB 5HP 1750 RPM 3PH ODP Pump

Keep multi-story HVAC circulation moving with Bell & Gossett Series e-1532 2.5BB, a 5 HP close-coupled footless pump operating at 1750 RPM. Its 3-inch suction and 2-1/2-inch discharge connections suit main-loop circulation in larger buildings, while the ODP motor and stainless-steel shaft sleeve provide defined equipment details for replacement matching. Confirm the electrical data, case layout, and impeller trim before installation.

The four-pole motor drives a nominal 9.5-inch impeller through the 2.5BB case arrangement. The footless design requires proper pipe support and alignment because the piping layout carries the pump assembly. Voltage, amp draw, flow, head, pressure, dimensions, weight, and seal material were not supplied, so verify the full submittal and foundation-free mounting requirements before startup.

Key Features & Benefits

- 5 HP Motor: Supports main-loop HVAC circulation and process-water transfer.
- 1750 RPM Speed: Provides a four-pole reference for steady commercial pumping.
- 3-Inch Suction: Accommodates the larger inlet connection listed for the 2.5BB case.
- 2-1/2-Inch Discharge: Defines the outlet size for compatible building HVAC piping.
- 9.5-Inch Nominal Impeller: Identifies the listed rotating component for system comparison.
- ODP Motor: Specifies the open drip proof enclosure for suitable indoor placement.
- NEMA JM Frame: Provides a frame reference for compatible pump and motor matching.
- Footless Construction: Requires proper pipe support and alignment within the installation.
- Stainless-Steel Shaft Sleeve: Provides the specified sleeve material for the rotating assembly.

Why Choose Bell & Gossett Series e-1532 2.5BB

The 2.5BB configuration combines larger connections, 5 HP power, and footless close-coupled construction for multi-story HVAC and process-water systems.

- Build: ODP motor, stainless-steel shaft sleeve, 2.5BB case, and footless layout define the supplied equipment.
- Value: A footless design can reduce separate base hardware, provided the piping is properly supported and aligned.
- Audience: Intended for commercial HVAC contractors, high-rise building engineers, process-water technicians, and facility maintenance teams.

Applications & Use Cases

Use Bell & Gossett Series e-1532 2.5BB for main-loop circulation, multi-story building HVAC, process-water transfer, and compatible large-pipe systems. The supplied data identifies 3-inch suction and 2-1/2-inch discharge connections but does not provide dimensions, weight, or port reach. Verify pipe support, lifting access, electrical clearance, and service space before installation.

Warranty & Support

- Warranty Terms Require Confirmation: Verify duration, coverage, registration, exclusions, and authorized service requirements with the seller.
- Confirm the 2.5BB case, 5 HP motor, 1750 RPM speed, ODP enclosure, frame, and impeller before purchase.

Inspect the suction and discharge piping, support the footless assembly, verify motor rotation, prime the pump, and purge air before startup. Monitor pressure, vibration, leakage, and bearing temperature during commissioning. Purchase the Bell & Gossett Series e-1532 2.5BB 5 HP footless centrifugal pump through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
