Confirm the performance curve before selecting Taco 1619C3E3 2 HP single-phase in-line centrifugal pump for high-head closed-loop HVAC. Its 115/230-volt motor draws 19.6A or 9.8A, while the supplied data lists 160 GPM flow and 62 feet of head. Taco’s current 1619 family range is listed at 9–97 GPM, so the supplied flow rating requires exact model and trim verification.

The 1619C3E3 uses a cast-iron bronze-fitted body, full-diameter cast-bronze impeller, and 1,725 RPM single-phase motor. Its 2-inch connection and 82-pound dry weight affect installation planning. The 65-foot shut-off head is a zero-flow reference. Seal, pressure, temperature, complete dimensions, and current manufacturer curve data are not supplied.

Key Features & Benefits

- 2 HP Motor: Supports high-head closed-loop HVAC circulation if the verified curve matches.
- 115/230-Volt Service: Provides single-phase flexibility after field verification.
- 19.6A/9.8A Current: Assists circuit and disconnect planning.
- 160 GPM Listed Flow: Requires confirmation because it exceeds Taco’s published 1619 family range.
- 62 Feet Listed Head: Must be matched to the exact impeller trim.
- 2-Inch Connection: Supports replacement planning when the piping matches.
- 82-Pound Dry Weight: Helps plan handling and support.

Why Choose Taco 1619C3E3

This Taco configuration offers a larger single-phase motor for high-head HVAC service. Its supplied flow value must be reconciled with Taco’s current 1619 family data before publication or purchase.

- Build: Cast iron, bronze-fitted construction, and full-diameter impeller define the supplied assembly.
- Value: Correct curve verification can prevent oversizing and commissioning problems.
- Audience: Fits HVAC contractors, boiler technicians, facility engineers, and commercial plant operators.

Applications & Use Cases

Consider this pump for high-head closed-loop HVAC only after the 160 GPM rating is confirmed. Check the 2-inch connection, pipe supports, valve clearance, motor access, phase protection, and 82-pound handling requirement before installation.

Warranty & Support

- Warranty Terms: Taco warranty duration and coverage for this 1600 Series configuration require confirmation under current commercial terms.
- Coverage Review: Confirm date-code requirements, seal exclusions, electrical conditions, and claim procedures before purchase.
- Model Verification: Match Taco 1619C3E3, 2 HP, single-phase configuration, and SKU 1619C3E3 to the seller’s order.

Verify the exact curve, voltage, current, impeller, and motor protection before wiring. Purchase the Taco 1619C3E3 single-phase in-line centrifugal pump at Mulmotor.com for genuine equipment, applicable warranty coverage, and pump support.
