Manage district-heating flow with Bell & Gossett 104315 ecocirc XL 70-145, a cast-iron ECM circulator for high-head secondary loops and commercial hydronic systems. Its 208–230 V single-phase motor, 70 feet maximum head, and 145 GPM maximum flow suit larger circuits where demand changes throughout the day. The push-button interface and LED indicators give technicians direct status feedback. Confirm the flange layout and control wiring before installation.

The ECM motor adjusts output within the XL 70-145 performance range, while the cast-iron body suits compatible closed-loop heating and cooling systems. Manufacturer reference data identifies the model as a 2 HP, 208–230 V single-phase pump with a 55 W to 1400 W power range. Verify amp draw, dimensions, weight, port reach, operating pressure, and service clearance against the current submittal before startup.

Key Features & Benefits

- 2 HP ECM Motor: Supports high-head and high-flow circulation in commercial hydronic systems.
- 70 Feet Maximum Head: Provides a selection reference for higher-resistance secondary loops.
- 145 GPM Maximum Flow: Handles substantial water volume in district-heating and HVAC circuits.
- 208–230 V Single-Phase: Fits compatible commercial electrical service without requiring three-phase power.
- Push-Button Interface: Gives technicians direct access to operating controls during setup.
- LED Status Indicators: Provide quick visual feedback during commissioning and service checks.
- 55 W to 1400 W Power Range: Helps review electrical demand across changing operating conditions.
- Cast-Iron Body: Suits compatible closed-loop hydronic heating and cooling systems.

Why Choose Bell & Gossett 104315 ecocirc XL 70-145

The ecocirc XL 70-145 combines substantial head and flow capacity with ECM control for larger hydronic systems where a fixed-speed circulator may not match changing demand.

- Build: Cast iron, ECM motor technology, integrated controls, and flanged construction define the supplied pump arrangement.
- Value: Electronic control and status feedback can simplify commissioning and operating adjustments.
- Audience: Suited to district-energy technicians, commercial HVAC contractors, facility engineers, and central-plant operators.

Applications & Use Cases

Use Bell & Gossett 104315 ecocirc XL 70-145 for high-head secondary loops, district heating, commercial HVAC, and compatible chilled-water systems. The supplied data identifies a standard flanged connection but does not provide overall dimensions, unit weight, or port reach, so verify pipe support, lifting access, control clearance, and service space before installation.

Warranty & Support

- Warranty Terms Require Confirmation: Verify duration, coverage, registration, exclusions, and authorized service requirements with the seller.
- Match SKU 104315, ecocirc XL 70-145 model, 2 HP rating, 208–230 V supply, head, and flow before ordering.

Flush the loop, purge air, verify the 208–230 V supply, and configure the selected operating mode before startup. Monitor flow, head, vibration, temperature, power draw, and LED status during commissioning. Purchase the Bell & Gossett 104315 ecocirc XL 70-145 ECM hydronic circulator through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
