Bell & Gossett 104450LF Ecocirc XL N 20-35 Stainless Steel Circulating Pump

Circulate potable water through domestic hot-water loops with Bell & Gossett 104450LF ecocirc XL N 20-35, a stainless-steel ECM circulator for 115 V single-phase service. Its 35 GPM maximum flow and 20 feet maximum head suit smaller commercial and institutional DHW systems where lead-free wetted materials and electronically controlled operation are important. Verify the system curve and connection details before installation.

The ECM motor uses the stainless-steel XL N body and operates within a 6 W to 85 W power range. Manufacturer reference data identifies a 1/12 HP nominal motor, 115 V single-phase supply, and NSF/ANSI 61 and 372 compliance for potable-water use. Confirm amp draw, dimensions, weight, port size, and control features against the current submittal before startup.

Key Features & Benefits

- 1/12 HP ECM Motor: Supports smaller commercial domestic hot-water circulation.
- 115 V Single-Phase: Fits compatible US service panels for straightforward connection.
- 35 GPM Maximum Flow: Handles smaller potable-water return systems within the verified range.
- 20 Feet Maximum Head: Provides a selection reference for lower-resistance DHW loops.
- 6 W to 85 W Power Range: Helps review electrical demand across changing operating conditions.
- Stainless-Steel Body: Provides the specified casing material for open-loop potable-water service.
- NSF/ANSI 61 and 372: Support the listed potable-water compliance requirements.
- ECM Operation: Allows electronically controlled circulation for changing DHW demand.

Why Choose Bell & Gossett 104450LF ecocirc XL N 20-35

The ecocirc XL N 20-35 combines stainless-steel construction, ECM control, and potable-water certifications for smaller commercial DHW loops.

- Build: Stainless-steel body, ECM motor, and potable-water compliance define the supplied configuration.
- Value: The broad power range can help limit unnecessary electrical use during lower demand.
- Audience: Suited to plumbing contractors, hotel maintenance teams, apartment engineers, and commercial DHW installers.

Applications & Use Cases

Use Bell & Gossett 104450LF ecocirc XL N 20-35 for potable-water recirculation, domestic hot-water loops, and compatible 115 V systems. The supplied data does not provide overall dimensions, unit weight, connection size, or port-to-port reach, so verify flange or threaded details, valve clearance, water temperature, and service access before installation.

Warranty & Support

- Warranty Terms Require Confirmation: Verify duration, coverage, registration, exclusions, and authorized service requirements with the seller.
- Match SKU 104450LF, ecocirc XL N 20-35 model, 115 V supply, stainless-steel body, flow, head, and certifications before ordering.

Flush the potable-water loop, purge air, verify the 115 V supply, and configure the ECM controls before startup. Monitor flow, temperature, vibration, leakage, and power draw during commissioning. Purchase the Bell & Gossett 104450LF ecocirc XL N 20-35 stainless-steel potable-water circulator through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
