Increase domestic hot-water circulation with Armstrong 182212-666 E21.2B, a lead-free bronze ARMflo pump for commercial potable-water systems. The supplied listing identifies 82 GPM and 31 feet of head, while Armstrong’s E21.2B submittal identifies approximately 90 GPM and 26.5 feet. Use the verified performance range when comparing this pump with the actual system curve.

The dry-rot two-pole motor operates at 3450 RPM on 120 V single-phase power. Permanently lubricated stainless-steel bearings reduce routine oiling, while the silicon carbide seal uses a Viton elastomer. Verified data lists 150 psi maximum working pressure and 230°F maximum fluid temperature. Confirm amp draw, dimensions, weight, flange size, and mounting orientation before installation.

Key Features & Benefits

- 2/3 HP Nominal Motor: Supports high-capacity potable-water and domestic hot-water circulation.
- 120 V Single-Phase: Fits compatible commercial service panels for straightforward connection.
- 90 GPM Maximum Flow: Handles larger recirculation demand within the verified E21.2B range.
- 26.5 Feet Maximum Head: Provides the corrected selection reference for system resistance.
- Lead-Free Bronze Body: Supports compatible open-loop and potable-water service.
- 3450 RPM Motor: Provides the verified speed reference for replacement matching.
- Silicon Carbide Seal: Helps manage shaft leakage with the specified Viton elastomer.
- Maintenance-Free Bearings: Reduce routine lubrication work during normal service.

Why Choose Armstrong 182212-666 E21.2B

The E21.2B offers lead-free bronze construction and verified high-flow circulation for commercial DHW systems where correct head selection matters.

- Build: Bronze body, dry-rotor motor, silicon carbide seal, and permanently lubricated bearings define the verified pump.
- Value: Corrected performance data helps prevent overestimating the pump’s available head.
- Audience: Suited to plumbing contractors, hospital maintenance teams, hotel engineers, and commercial water-system installers.

Applications & Use Cases

Use Armstrong 182212-666 E21.2B for commercial potable-water circulation, high-capacity DHW loops, and compatible open systems. Verified data identifies approximately 90 GPM and 26.5 feet of head, with 150 psi maximum pressure. Confirm flange spacing, dimensions, weight, indoor orientation, valve clearance, and service access before installation.

Warranty & Support

- Warranty Terms Require Confirmation: Verify duration, coverage, registration, exclusions, and authorized service requirements with Armstrong or the seller.
- Request confirmation of the corrected E21.2B flow, head, motor data, voltage, and flange configuration before ordering.

Flush the line, purge air, verify the 120 V supply, inspect the seal, and compare operation with the verified curve. Purchase the Armstrong 182212-666 E21.2B ARMflo lead-free bronze circulator through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
