Handle higher-resistance potable-water circulation with Armstrong 182212-668 E22.2B, a lead-free bronze ARMflo circulator for solar thermal and domestic hot-water systems. The supplied listing shows 60 GPM and 43 feet of head, while Armstrong’s current E22.2B submittal identifies approximately 88 GPM and 39.5 feet. Use the verified ratings for final pump selection.

The dry-rot, two-pole motor operates at approximately 3350 RPM on 120 V single-phase power. The pump uses permanently lubricated stainless-steel bearings and a silicon carbide seal with Viton elastomer. Verified data lists 150 psi maximum working pressure and 230°F maximum fluid temperature. Confirm amp draw, dimensions, weight, flange details, and indoor orientation before startup.

Key Features & Benefits

- 2/3 HP Nominal Motor: Supports high-head potable-water and solar-thermal circulation.
- 120 V Single-Phase: Fits compatible commercial service panels without requiring three-phase power.
- 88 GPM Maximum Flow: Handles substantial hot-water circulation within the verified E22.2B range.
- 39.5 Feet Maximum Head: Provides the corrected reference for higher-resistance systems.
- Lead-Free Bronze Body: Supports compatible potable-water and open-loop applications.
- 3350 RPM Motor: Provides the verified speed reference for equipment matching.
- Silicon Carbide Seal: Helps contain fluid around the shaft with a Viton elastomer.
- Permanently Lubricated Bearings: Reduce routine lubrication work during normal operation.
- 150 psi Maximum Pressure: Establishes the verified pressure boundary for compatible systems.

Why Choose Armstrong 182212-668 E22.2B

The E22.2B combines lead-free bronze construction with verified high-flow and high-head capability for commercial potable-water and solar-thermal systems.

- Build: Bronze body, dry-rot motor, silicon carbide seal, and sealed bearings define the verified arrangement.
- Value: Corrected flow and head information helps prevent inaccurate system selection.
- Audience: Suited to solar-thermal installers, plumbing contractors, hotel engineers, and commercial DHW teams.

Applications & Use Cases

Use Armstrong 182212-668 E22.2B for high-head potable-water recirculation, solar thermal systems, and compatible DHW loops. Verified data identifies approximately 88 GPM and 39.5 feet of head, with 150 psi maximum pressure. Confirm flange spacing, water temperature, indoor orientation, valve clearance, and service access before installation.

Warranty & Support

- Warranty Terms Require Confirmation: Verify duration, coverage, registration, exclusions, and authorized service requirements with Armstrong or the seller.
- Request confirmation of the corrected E22.2B flow, head, motor data, voltage, and flange configuration before ordering.

Flush the loop, purge air, verify the 120 V supply, inspect the seal, and monitor flow, vibration, temperature, and leakage during commissioning. Purchase the Armstrong 182212-668 E22.2B ARMflo lead-free bronze circulator through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
