Keep medium-head commercial hydronics moving with Bell & Gossett 172738LF 608T, a 1/2 HP Series 60 pump for three-phase HVAC zones and secondary heating loops. Its cast-iron bronze-fitted body and 1-1/2-inch connection size provide clear replacement references for compatible mechanical-room piping. The 4.94-inch bronze impeller completes the identification, but the system curve must still be checked before installation.

The 208–230/460 V three-phase motor drives the bronze impeller within a maintenance-free Series 60 assembly. The carbon, ceramic, and Buna-N mechanical seal manages fluid around the shaft, while the three-piece construction supports the specified pump arrangement. The supplied data does not state flow, head, amp draw, dimensions, or weight, so verify those details against the current submittal.

Key Features & Benefits

- 1/2 HP Motor: Supports medium-head circulation in compatible commercial hydronic systems.
- Three-Phase Operation: Fits 208–230/460 V service for commercial electrical compatibility.
- 1-1/2-Inch Pump Size: Helps contractors compare the pump with existing flanged piping.
- 4.94-Inch Bronze Impeller: Provides a clear rotating-component reference for replacement matching.
- Cast-Iron Bronze-Fitted Body: Combines the specified casing with a bronze impeller for compatible hydronic service.
- Maintenance-Free Series 60 Design: Reduces routine lubrication work during normal hydronic operation.
- Carbon/Ceramic/Buna-N Seal: Helps contain circulating fluid around the shaft.

Why Choose Bell & Gossett 172738LF 608T

The 608T combines a 1-1/2-inch connection size, bronze impeller, and three-phase motor in a Series 60 arrangement suited to commercial HVAC zones and secondary heating loops.

- Build: Cast iron, bronze impeller, three-piece construction, and specified seal materials identify the pump assembly.
- Value: Maintenance-free Series 60 construction can reduce routine lubrication tasks during normal service.
- Audience: Suited to commercial HVAC contractors, boiler technicians, facility engineers, and hydronic replacement specialists.

Applications & Use Cases

Use Bell & Gossett 172738LF 608T for medium-head three-phase hydronics, commercial HVAC zones, boiler branches, and compatible secondary heating loops. Manufacturer reference data lists a 1-1/2-inch by 1-1/2-inch by 5-1/4-inch pump size, an approximate 21-7/16-inch overall height, and a 61-pound approximate weight. Confirm the exact installation drawing before ordering.

Warranty & Support

- 3-Year Limited Warranty: Series 60 maintenance-free pump warranty coverage should be confirmed against the current manufacturer terms.
- Match SKU 172738LF and model 608T against the existing nameplate, pump size, phase, and voltage.

Fill and vent the loop, flush the piping, inspect the mechanical seal and flange gaskets, and confirm correct three-phase rotation. Monitor vibration, sound, leakage, and motor temperature during commissioning, then compare operation with the approved system curve. Purchase the Bell & Gossett 172738LF 608T Series 60 commercial hydronic pump through Mulmotor.com for authentic equipment, applicable warranty support, and pump assistance.
