2018 Tohatsu 5 Hp MFS5CL Outboard Motor

2018 Tohatsu 5 Hp MFS5CL? Outboard Motor

Tohatsu’s 5hp outboard motor delivers outstanding fuel economy and reliability second to none. The Tohatsu 5hp model MFS5CL comes equipped with the 20 inch long shaft and is a great source of portable power for jon boats, skiffs, and inflatables, as well as auxiliary power for sailboats and “kickers” for larger fishing boats.
The Tohatsu 5hp outboard engine shares many 4hp features with the added benefit of a larger carburetor and propeller for increased performance. Fuel is delivered via a portable 3.1 gallon external fuel tank and fuel line (included).).

2018 Tohatsu 5 Hp MFS5CL? Outboard Motor

- Newly Redesigned 2013 “C” Model
- Advanced Digital CD Ignition System
- Low Oil Pressure Warning Indicator
- ESG Over Rev RPM Limiter
- High Grade Marine Alloy Construction
- Stainless Steel Water Pump Housing
- Zinc Coated Water Passages
- Sacrificial Zinc Anodes
- Adjustable Steering Friction Setting
- Forward Mounted? Gear Shift Selector
- Twist-Grip Throttle with Tension Control
- Integrated Carrying Handle
- Start-In-Gear Protection
- Thermostatically Controlled Cooling
- Advanced Cross Flow Induction System
- Shallow Water Drive; 6 Trim Positions
- Quiet Through-The-Propeller Exhaust
- 3.1 Gallon Fuel Tank / Fuel Line
- Safety Lanyard Cut-Off Switch
- Operating Manual & Emergency Tool Kit
- Tohatsu 5-Year Warranty

2018 Tohatsu 5 Hp MFS5CL? Outboard Motor

MODEL MFS5CL

MODEL YEAR 2018

SKU MFS5CL-18

WEIGHT 59.0000

MANUFACTURER Tohatsu

COUNTRY OF MANUFACTURE Japan

HORSEPOWER 5hp

SHAFT LENGTH 20″ (Long)

STEERING Tiller

STARTING Manual

TRIM & TILT Manual

FUEL DELIVERY Carburetor

FUEL TANK External

CYLINDER(S) 1

DISPLACEMENT 123 cc (7.5 cubic inches)

BORE AND STROKE 59 x 45 mm (2.32 x 1.77 inches)

FULL THROTTLE RPM RANGE 4,500-5,500 RPM

IGNITION SYSTEM Digital CD Ignition

INDUCTION SCAVENGING OHV

VALVES PER CYLINDER 2

FUEL TYPE Unleaded Gasoline (87 octane)

FUEL TANK / FUEL LINE 3.1 Gal. Fuel Tank + Quick Connect Fuel Line

OIL TYPE SAE 10W-30 or SAE 10W-40 (SF, SG, SH, SJ)

OIL CAPACITY 15 fl. oz. (450 ml)

LUBRICATION Wet Sump

ALTERNATOR Optional 12V 60W 5A (installation required)

COOLING SYSTEM Water-Cooled, Thermostatically Controlled

SALTWATER RATED Yes

GEAR RATIO 2.15:1

GEAR SHIFT Forward-Neutral-Reverse (front mount shifter)

PROPELLER 7.7″ Dia. X 8.0″ Pitch 3-Blade Aluminum

INTERNAL BATTERY No

2018 Tohatsu 5 Hp MFS5CL? Outboard Motor

WHAT’S IN THE BOX?

- Fuel Tank (3.1 gallon)
- Quick Connect Fuel Line
- Aluminum Propeller
- Owner’s Manual & Tool Kit
- Tohatsu 5-Year Warranty
